LumiScan AI Object Matching is an application that uses neural networks to find objects in images.
It returns the position and orientation of an object in pixel coordinates. That enables the detection of unknown objects or specific shapes of components on the production line. It can also be used to detect product defects such as scratches.
The application runs on ctrlX OS devices like ctrlX CORE and its interface is ctrlX Data Layer. It is installed via the ctrlX OS Store and configured via a settings file.
Features
Setup and control via ctrlX Data Layer.
Suppors monochrome 8-bit and 16-bit images.
The settings configuration can be edited with built-in website.
To use the LumiScan AI Object Matching application, you must upload a neural network model.
Optionally, if you want to use your own settings, an application configuration upload is also possible.
Both can be done with WebDAV.
Compatibilty
ctrlX OS Version 2.6
Prerequisites
Neural Network Models provided by LumiScan Training Framework software.
ctrlX OS
Documentation
Support
HD Vision Systems Customer Service
+49 (0)6221 6721905
HD Vision Systems Customer Service 1)
Related Links
Curious?
You can test many apps free of charge with a virtual control system provided by ctrlX WORKS.
Just download ctrlX WORKS and follow this How-to
[link-button type="light" text="TRY IT NOW" target="_blank" href="https://community.boschrexroth.com/ctrlx-os-store-apps-oc2pqqwn/post/ctrlx-works-xOJLFLUiK4NGm5H"]
The Company
HD Vision Systems supports manufacturing companies in all aspects of Machine Vision.
With its unique light field-based technology, their systems offer customers fast and easy access to automation: the light field makes it possible to reliably detect complex and shiny surfaces or fibre composites. The flexible systems consisting of sensor and software are also highly adaptable for small quantities. Each vision solution from HD Vision Systems is supplied together with a vision controller mounted on the edge. The system can then be used flexibly for various applications: In addition to generating high-precision RGB-D point clouds of detected objects and object recognition, they also provide accurate object localization and inspection.
