LumiScan Cockpit is the central visualization and management interface for the LumiScan Vision Suite, running natively on Bosch Rexroth ctrlX OS. Designed for clarity, speed, and operational efficiency, the Cockpit provides a unified environment to monitor, configure, and optimize all installed LumiScan vision applications.
With LumiScan Cockpit, operators and engineers gain immediate insight into the status and functionality of every vision module in the system.
Key Features
Centralized App Visualization
View and manage all LumiScan Vision Suite applications from a single interface. The Cockpit provides a structured overview of installed modules and their operational status.
License Awareness
Automatically detects which LumiScan apps are licensed and available on the system. Only licensed modules can be activated and configured, ensuring transparent system capabilities and compliance.
Live Image Information
Access image streams and detailed image metadata directly within the Cockpit. This allows users to verify acquisition quality, inspect processing results, and quickly diagnose issues.
Parameter Tuning
Fine-tune the relevant parameters of each LumiScan application directly from the interface. The Cockpit enables fast adjustment of processing settings, allowing users to optimize performance and adapt to changing production conditions.
Seamless ctrlX OS Integration
Running as a native ctrlX OS app, LumiScan Cockpit integrates smoothly into the Bosch Rexroth ctrlX OS ecosystem, benefiting from its modular architecture, reliability, and industrial performance.
Benefits
Single point of control for the entire LumiScan Vision Suite
Faster setup and commissioning of vision applications
Transparent licensing overview
Improved diagnostics through live image data
Efficient parameter optimization
LumiScan Cockpit transforms complex machine vision deployments into a clear, manageable, and configurable system, giving users full control over their LumiScan-powered inspection workflows.
Compatibilty
ctrlX OS Version 3.6
Prerequisites
Ethernet-enabled, GenICam compliant camera
ctrlX OS
At least one of the following applications installed:
LumiScan AI Object Matching
LumiScan CamDriver
